Emulex Fibre Channel Host Bus Adapters
LP8000 Host Adapter Information
Prerequisites
LP8000 specifications
FCC and regulatory notices
|
| Caution |
Emulex LightPulse Host Bus Adapters (HBAs) contain electronic components that can be damaged by static electricity through an electrostatic discharge (ESD) event. To prevent ESD damage, maintain frequent contact with any grounded metal surface. A grounding wrist strap is useful for this purpose. Handle the card carefully at all times and preferably by the edges. Avoid touching electronic components and keep the card in the original packaging until you are ready for installation. |
|
Prerequisites
- One open 32-bit or 64-bit (recommended) PCI bus slot with a 3.3 VDC or 5.0 VDC signaling interface
- Maximum PCI bus clock rate of 33 MHz
- Media and connectors (user supplied)
- Multimode fiber optic cable (50/125 m m or 62.5/125 m m) with dual SC connectors, used with short wave lasers
- Single mode fiber optic cable (9/125 m m) with dual SC connectors, used with long wave lasers
- Copper duplex cabling with DB9 connectors (also called DE9)
LP8000 Host Adapter Specifications
Parameter |
Range |
| Hardware Interface | 20 pin connector for GBIC models |
| Physical Dimensions | Short PCI form factor 6.88" x 4.20" |
| Power Requirements | 11 watts @ + 5.0 VDC (typical) |
| Airflow | 100 lfm minimum |
| Temperature |
Operating: 32° to 113° F (0° to 45° C)
Storage: 14° to 131° F (-10° to 55° C) |
| Humidity | 5% to 95% non-condensing |
Agency Approvals for
LP8000-D1 |
UL recognized to UL1950
CUR recognized to CSA22.2, No. 950
TUV certified to EN60950
FCC Rules, Part 15, Class A
Industry Canada, ICES-003, Class A
EMC Directive 89/336/EEC (CE Mark)
EN55022, Class A
EN50082-1
Australian EMC Framework (C-Tick Mark)
AS/NZS 3548:1994, Class A
VCCI, Class A. |
Agency Approvals for
LP8000-N1/T1/L1
and LP8000-F1
|
Class 1 Laser Product per DHHS 21CFR (J) & EN60825
UL recognized to UL1950
CUR recognized to CSA22.2, No.950
TUV certified to EN60950
FCC Rules, Part 15, Class B
Industry Canada, ICES-003, Class B
EMC Directive 89/336/EEC (CE Mark)
EN55022, Class B
EN50082-1
Australian EMC Framework (C-Tick Mark)
AS/NZS 3548:1994, Class B
VCCI, Class B |
FCC and Regulatory Notices
|
CLASS 1 LASER PRODUCT
LASER KLASSE 1
LUOKAN 1 LASERLAITE
APPAREIL A` LASER DE CLASSE 1
TO IEC 825-1 (1993) + CENELEC HD 482 S1 |
The above statement applies to products marketed in the European Union.
Model LP8000-D1 (Embedded Copper)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Shielded cables must be used between this equipment and attached peripheral devices. The reader is cautioned that changes or modifications made to the equipment not expressly approved by Emulex could void the user’s authority to operate this equipment.
The above statement applies to products marketed in the USA
This class A digital apparatus meets all requirements of the Canadian Interference - Causing Equipment Regulations. Cet Appareil numerique de la classe A respecte toutes les exigences du reglement sur le matériel brouilleur du Canada.
The above statement applies to products marketed in Canada.
FCC Compliance Information Statement; Models LP8000-N1/L1/T1 (GBIC Models):
FCC Compliance Information Statement; Model LP8000-F1 (1 X 9):
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Responsible Party: Paul Folino, President & CEO, Emulex Corporation, 3535 Harbor Blvd., Costa Mesa, CA 92626, USA, (714) 662-5600
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The reader is cautioned that any changes or modifications to the equipment not expressly approved by Emulex could void the user’s authority to operate this equipment.
This class B digital apparatus meets all requirements of the Canadian Interference - Causing Equipment Regulations. Cet Appareil numerique de la classe B respecte toutes les exigences du reglement sur le material brouilleur du Canada.
The above statement applies to products marketed in Canada.
|
|
|
|
|
|
